Asus Prime B850M-F WIFI (Socket AM5) DDR5 Micro-ATX Motherboard
Product Technical Specification
| Form Factor | |
| Motherboard formfactor | Micro-ATX |
| Wi-Fi & LAN | |
| LAN | Yes |
| LAN Ports | 1x 2.5 Gbit/s |
| Wi-Fi / Bluetooth | Yes |
| Motherboard | |
| Motherboard Chipset | AMD B850 |
| CPU | |
| CPU Manufacturer | AMD |
| CPU Socket | AM5 |
| Colour | |
| Primary Colour | Black |
| Lighting | |
| Lighting / RGB | Yes |
| Fan Header | |
| 4 Pin Fan Connectors | 6 |
| Memory | |
| Max. Memory | 256 GB |
| Memory Type | DDR5 |
| Memory Form Factor | DIMM |
| Memory slots | 4x |
| Internal Ports | |
| CPU Power Supply | 1x 4-Pin + 1x 8-Pin |
Delivery Options
Economy Delivery (UK)
Business Express
| Model | PRIME B850M-A WIFI |
|---|---|
| CPU | AMD Socket AM5 for AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors. * Refer to ASUS Support for CPU support list. |
| Chipset | AMD B850 Chipset |
| Memory |
4 x DIMM slots, max. 256GB DDR5 Supports up to 8000+MT/s (OC) Dual Channel Architecture Supports ECC and Non-ECC Un-buffered DIMM AMD EXPO™ & ASUS Enhanced Memory Profile (AEMP) support * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics |
2 x DisplayPort (max. 8K@30Hz, DisplayPort 1.4) 1 x HDMI™ port (4K@60Hz, HDMI 2.1) * Graphics specifications may vary by CPU. |
| Expansion Slots |
AMD Ryzen™ 9000 & 7000 Series: 1 x PCIe 5.0 x16 (x16 mode) AMD Ryzen™ 8000 Series: 1 x PCIe 4.0 x16 (x8/x4 mode) AMD B850 Chipset: 1 x PCIe 4.0 x16 (x1 mode) * See PCIe bifurcation table for details. |
| Storage |
3 x M.2 slots, 4 x SATA 6Gb/s ports Ryzen™ 9000 & 7000: M.2_1 – PCIe 5.0 x4 M.2_2 – PCIe 4.0 x4 Ryzen™ 8000: M.2_1 – PCIe 4.0 x4 M.2_2 – PCIe 4.0 x4/x2 B850 Chipset: M.2_3 – PCIe 4.0 x4 (2242/2260/2280) AMD RAIDXpert2 Technology Ryzen™ 9000: RAID 0/1/5/10 Ryzen™ 8000: RAID 0/1 Ryzen™ 7000: RAID 0/1/10 |
| Ethernet | 1 x Realtek 2.5Gb Ethernet with ASUS LANGuard |
| Wireless & Bluetooth |
Wi-Fi 6E (802.11ax), 2x2, supports 2.4/5/6GHz Bluetooth® v5.3 * Wi-Fi 6E availability varies by region. |
| USB |
Rear I/O (8 ports): 2 x USB 10Gbps Type-A 2 x USB 5Gbps Type-A 4 x USB 2.0 Type-A Front (7 ports): 1 x USB 5Gbps Type-C 1 x USB 5Gbps header (2 ports) 2 x USB 2.0 headers (4 ports total) |
| Audio |
Realtek 7.1 Surround Sound HD Audio CODEC Jack-detection, Multi-streaming, Front Panel Jack-retasking 24-Bit/192 kHz playback Audio Shielding, Premium capacitors, Dedicated audio PCB layers |
| Back Panel I/O |
2 x USB 10Gbps (Type-A), 2 x USB 5Gbps (Type-A), 4 x USB 2.0 (Type-A) 2 x DisplayPort, 1 x HDMI™, 1 x Wi-Fi module 1 x Realtek 2.5Gb LAN, 3 x Audio jacks 1 x BIOS FlashBack™ button |
| Internal I/O |
1 x 4-pin CPU Fan, 1 x 4-pin CPU OPT, 1 x 4-pin AIO Pump 3 x 4-pin Chassis Fan headers 24-pin Main Power, 8-pin +12V CPU, 4-pin +12V CPU 3 x M.2 slots, 4 x SATA 6Gb/s RGB/ARGB, TPM, COM, Front Panel Audio, Clear CMOS, S/PDIF, System Panel headers |
| Special Features |
ASUS 5X PROTECTION III, ASUS Q-Design, ASUS Thermal Solution, ASUS EZ DIY Aura Sync RGB |
| Software |
Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 2+) ASUS AI Advisor, Driver Hub, GlideX, TurboV Core, CPU-Z Norton 360 Deluxe (60 Days), WinRAR (40 Days) |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories |
2 x SATA 6Gb/s cables 1 x ASUS WiFi Q-Antenna 1 x M.2 rubber package 2 x M.2 SSD screw packages 1 x Quick start guide |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Form Factor | mATX (24.4 cm x 24.4 cm / 9.6 inch x 9.6 inch) |
| Form Factor | |
| Motherboard formfactor | Micro-ATX |
| Wi-Fi & LAN | |
| LAN | Yes |
| LAN Ports | 1x 2.5 Gbit/s |
| Wi-Fi / Bluetooth | Yes |
| Motherboard | |
| Motherboard Chipset | AMD B850 |
| CPU | |
| CPU Manufacturer | AMD |
| CPU Socket | AM5 |
| Colour | |
| Primary Colour | Black |
| Lighting | |
| Lighting / RGB | Yes |
| Fan Header | |
| 4 Pin Fan Connectors | 6 |
| Memory | |
| Max. Memory | 256 GB |
| Memory Type | DDR5 |
| Memory Form Factor | DIMM |
| Memory slots | 4x |
| Internal Ports | |
| CPU Power Supply | 1x 4-Pin + 1x 8-Pin |
